Дънна платка ASRock B560M-HDV R2.0 DDR 4 LGA1200

CPU Socket: 1200
Чипсет: Intel B560
Поддържани процесори: Supports 10th Gen Intel® Core™ Processors and 11th Gen Intel® Core™ Processors (LGA1200)
Форм фактор: Micro ATX
Поддържана памет: DDR4
Максимален капацитет RAM памет: 64 GB
Слотове памет: 2
Честота памет: 11th Gen Intel® Core™ Processors support DDR4 non-ECC, un-buffered memory up to 5000+(OC), 10th Gen Intel® Core™ Processors support DDR4 non-ECC, un-buffered memory up to 4600+(OC)
Поддръжка на Dualchannel: Да
Вградено аудио: 7.1 CH HD Audio (Realtek ALC897 Audio Codec), Supports Surge Protection
Вграден LAN: Gigabit LAN 10/100/1000 Mb/s, Giga PHY Intel® I219V, Supports Wake-On-LAN
Слотoве PCI-E x16: 1
Слотoве PCI-E x1: 2
Интерфейс Serial ATA: 4 x SATA3 6.0 Gb/s
М2 слот: 1 x Ultra M.2 Socket (M2_2), supports M Key type 2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s), 1 x Hyper M.2 Socket (M2_1), supports M Key type 2260/2280 M.2 PCI Express module up to Gen4x4 (64 Gb/s) (Socket M2_1 works with 11th Gen Intel® Core™ processors only)
Конектор захранване: 1 x 24 pin ATX Power Connector, 1 x 8 pin 12V Power Connector
Видео слот: PCI Express
Свързаност: - 1 x PS/2 Mouse/Keyboard Port - 1 x D-Sub Port - 1 x DVI-D Port - 1 x HDMI Port - 2 x USB 2.0 Ports (Supports ESD Protection) - 4 x USB 3.2 Gen1 Ports (Supports ESD Protection) - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) - HD Audio Jacks: Line in / Front Speaker / Microphone
USB 3.2: 4
USB 2.0: 2
Размери: 24.4 cm x 19.8 cm
Комплектът включва: Quick Installation Guide, Support CD, I/O Shield, 2 x SATA Data Cables, 2 x Screws for M.2 Sockets
